Kipon Tilt and Shift Adapter for Hasselblad V to Canon EOS

Kipon T&S HB-EOS adapter is designed for the Canon EOS camera, allowing Hasselblad V mount lenses to be
mounted onto Canon EOS camera bodies.
Besides the original functions, the adapter also provide a 360°free rotation and a 12°tilt and 15mm shift
function. This provides the adapter with the flexibility to be adjusted accordingly to meet the needs of every
situation. The tilt function enables you to highlight specific subjects in a photo while the shift function minimize
an size distortions that may result from objects being seen at an angle.

On the right of the adapter a screw can be loosened to adjust the angle of the tilt. After adjustment, retighten
the screw to lock desired position into place. To adjust the shift, press the metal trigger and slide the moving piece
of the adapter. Please note that some specific lenses are not compatible with this adapter due to protruding inner
glass on the lens mount.

With KIPON T&S HB-EOS adapter, although the lens will fit physically, automatic diaphragm, auto-focusing,
and other functions will not work, only manual model will be available.

Features

1. Durable, high quality

2. Made of Alum or Brass, with perfect surface finishing and super precise design

3. Focus infinity feature is available for use with our camera adapter

4. 360º Rotation and shift with same axis

5.Approx. Tilt angle 12º

6.Maximum shift: 15mm
